ATR224-12ABC

PID controller with 1 control loop and four setpoints, dimensions 48 x 48 mm (front panel) x 80 mm, 1 analog input with multiple sensor configuration options, 1 PNP digital input, 2 digital relay outputs 2 A, 1 PNP digital output 12/24 Vdc 25 mA max (SSR), extended AC/DC power supply range 24...230 V, 4 white digits + 5 red digits display + 6 indication LEDs/memo, IP65 front panel protection with gasket, IP20 terminal blocks
