VVF22.40-16

Two-way globe valve, DN40 PN6 KVS= 16, for hot or cold water, cast iron body EN-GJL-250 with flanged connections, sealing system composed of brass elements, EPDM o-rings, PTFE sleeve, logarithmic port A-AB control characteristic (linear up to 0...30%), port A-AB leakage < maximum 0.02% of Kvs, fluid temperature limits -10...+130 °C, can be coupled with SAX, SKD, SKB and SKC series actuators. Maximum applicable differential pressure: see technical bulletin with reference to the type of actuator applied.
