Item code
VVF43.65-65
On backorder
Description
Two-way globe control valve, DN65 PN16 KVS= 63, stroke 40 mm, for hot or cold water, ductile iron body EN-GJS-400-18-LT with flanged connections, stainless steel stem and sealing system, FEPM seals, A-AB port logarithmic control characteristic (linear up to 0...30%), A-AB port leakage < maximum 0.01% of Kvs, fluid temperature limits -20...+200 °C, can be coupled with SAV or SKC series actuators. Maximum applicable differential pressure: see technical bulletin with reference to the type of actuator applied
Technical specifications
PROPERTY
VALUE
Connections
Flangiato
Ways
2 vie
Operating temperature
-25…+350 °C
Weight
21.5 kg
